Explosion-Proof Lamp 60W-110W | China Suppliers Factory | Flameproof LED with 10 Years Life for Hazardous Areas

This high-quality lamp is specifically engineered for high-risk explosive gas environments, making it an ideal choice for China suppliers and factories operating in Zone 1 and Zone 2 locations. It adheres to stringent safety standards for Class IA, IB, and I1C gases, with temperature classifications ranging from T1 to TAvailable power options include 60W, 70W, 80W, 90W, and 100W, ensuring optimal high-rise and high-space lighting solutions for warehouses, Our cutting-edge KWCOB fluorescent crystal kilowatt-level light source features a low thermal resistance packaging process that effectively reduces the center temperature, extending the service life of the light source while minimizing light decay, The lamp's construction boasts a robust high-strength aluminum alloy die-cast shell, featuring a radiant hollow structure for the central heat conduction column. An independent cooling system with an upper and lower channel honeycomb structure, along with a dust-proof cover, ensures efficient and reliable heat dissipation, Equipped with a KWCOB light source paired with a high borosilicate glass lens, this product offers an effective light distribution solution that minimizes upper light overflow, ensuring uniformity and comfort suitable for various application environments, With a standard five-year warranty and an option for a customized ten-year lifespan solution, this lamp is designed to meet the needs of contract energy management projects, particularly in petrochemical plant areas. Choose our lamp for safe, efficient, and reliable lighting solutions in your facility

Cut Off Design

KWCOB light source has high power and small emitting surface, with optical design advantages. Each light source has an independent optical system that can be matched with different lampshades to meet different light interception designs, providing a low glare and high comfort lighting environment.

Premium Optical Materials

The design employs mirror reflector cups and glass lenses for optics, avoiding the use of PC and PMMA plastic optical materials, ensuring the long service life of optical components is not constrained by material aging.

Wide Power Range

Product plan covering 80W-500W whole lamp.

Mature Packaging Technology

Fluorescent Crystal New Materials: Excellent thermal quenching characteristics, higher light conversion efficiency, lower attenuation.
Independent Patent: Fluorescent crystal kilowatt level COB light source packaging technology invention team.
Thermal Management: Structural design strengthens the center's heat extraction capability, providing reliable heat dissipation for COB.
High Adaptability: Can be paired with aluminum or ceramic substrate COB light sources, capable of replacing and adapting to high-voltage isolation and non-isolation drivers.

Long Life Cycle

The separation design of light source heat dissipation and drive heat dissipation can provide customized products with a long life of 5-10 years.

Honeycomb Heat Dissipation

Ensuring vertical ventilation structure, avoiding dust accumulation while ensuring better air circulation, and better adapting to harsh environments.

Personalized Customization

OPM provides professional design and customization services, offering a full lifecycle cost reduction solution for low glare explosion-proof lighting scenarios in high-risk explosive gas environments worldwide.

Installation Type

Flameproof Type Explosion-proof Lamp 2 Installation

Technical Parameters

Item	ZKXY-EXB01C060A	ZKXY-EXB01B070A	ZKXY-EXB01B080A	ZKXY-EXB01B090A	ZKXY-EXB01B100A	ZKXY-EXB01B110A
Power	60W	70W	80W	90W	100W	110W
Luminous Efficiency	≥120lm/w	≥120lm/w	≥120lm/w	≥120lm/w	≥120lm/w	≥120lm/w
Product Dimensions	φ200mm*H190mm	φ252mm*H243mm
Net Weight	5.0KG	7.2KG
CRI(Ra)	≥70, 80
Color Temperature	2700-6500K (Standard 5000K)
IP Rating	IP65
The Beam Angle	60° / 90° / 120°
Gold Thread	G3/4”
Application scenarios: Chemical plants, refineries, gas stations, hazardous chemical sites, etc.

Part of the Light Distribution Curves

Flameproof Type Explosion-proof Lamp 2 Distribution Curve

Frequently Asked Questions (FAQ)

What is the power range of your whole lamp product plan?

Our product plan covers a wide range from 80W to 500W whole lamps.

What is the advantage of your optical design?

We use KWCOB light sources with an independent optical system, mirror reflector cups, and glass lenses. We avoid plastic materials to ensure a long service life without material aging.

What kind of thermal management do your COB light sources have?

They feature a honeycomb heat dissipation structure for vertical ventilation, which avoids dust accumulation, and an optimized thermal management structure to strengthen the center's heat extraction capability.

What is the expected life cycle of your customized products?

Through the separation design of light source heat dissipation and drive heat dissipation, we can provide customized products with a long lifespan of 5 to 10 years.

Where can these explosion-proof lamps be applied?

They are widely applied in chemical plants, refineries, gas stations, hazardous chemical sites, and other high-risk explosive gas environments.

Do you offer personalized customization services?

Yes, we provide professional design and customization services, offering full lifecycle cost reduction solutions for low glare explosion-proof lighting scenarios.
